payment-gateway

Introduction

The application uses MongoDB to store the transactions, it uses grpc-gateway to expose the REST on the port 8080 and grpc 50051.

Endpoints contract

To test the grpc calls it is possible to use BloomRPC and get the grpc client contract from the proto file of the application here. The grpc-gateway generate the swagger to documentation for the REST endpoint, it is possible to see the contract here

Testing

The application contains unit tests, integration tests and e2e tests. The command to run the unit test is go test ./... -v To run the integration tests and e2e test the command is go test ./... -v -tags=integration (MongoDB container is required to run these tests).

Build and Run the application

It is possible to use the make all to run the unit tests and build the application and the docker-compose up to build the docker containers for the payment-gateway application and MongoDB. The docker-compose links the container in automatic, the docker-compose file is here.

make all
docker-compose up

The docker-compose expose the ports 8080 (REST) and 50051 (GRPC).

Test the application

health

The health endpoint show the status of the application

curl -X GET \
  http://localhost:8080/health \
  -H 'cache-control: no-cache' \
  -H 'postman-token: e0a69579-575a-3b95-285d-9e7cc58f7c46'

response 200 OK

{
    "status": "UP"
}

/v1/authorize

authorize the transaction

curl -X POST \
  http://localhost:8080/v1/authorize \
  -H 'cache-control: no-cache' \
  -H 'content-type: application/json' \
  -H 'postman-token: 3366ca89-6aef-2ac2-889f-b675d9a218c2' \
  -d '{
	"card": {
		"name": "Andrea Vasapollo",
		"card_number": "4242424242424242",
		"expire_month": "12",
		"expire_year": "2022",
		"cvv": "123"
	},
	"amount": {
		"value": 100,
		"currency": "EUR"
	}
}'

response 200 OK

{
    "result": "ok",
    "authorization_id": "b0b555e2-beb8-4f1a-9485-74bd499c845d",
    "amount": {
        "value": 100,
        "currency": "EUR"
    }
}

/v1/void

void the transaction

curl -X POST \
  http://localhost:8080/v1/void \
  -H 'cache-control: no-cache' \
  -H 'content-type: application/json' \
  -H 'postman-token: fffdce69-fd2b-54d0-d21e-616ae78d856e' \
  -d '{
	 "authorization_id": "b0b555e2-beb8-4f1a-9485-74bd499c845d"
}'

response 200 OK

{
    "result": "ok",
    "amount": {
        "value": 100,
        "currency": "EUR"
    }
}

/v1/capture

capture the transaction

curl -X POST \
  http://localhost:8080/v1/capture \
  -H 'cache-control: no-cache' \
  -H 'content-type: application/json' \
  -H 'postman-token: 2d7b93d8-89f5-8a9b-8d3d-85d9f4225841' \
  -d '{
	 "authorization_id": "4f3b8ee1-7a8b-4dc9-bdae-e63e6f0ad9f5",
	 "amount": 10
}'

response 200 OK

{
    "result": "ok",
    "amount": {
        "value": 90,
        "currency": "EUR"
    }
}

/v1/refund

refund the transaction

curl -X POST \
  http://localhost:8080/v1/refund \
  -H 'cache-control: no-cache' \
  -H 'content-type: application/json' \
  -H 'postman-token: 4002b371-9664-743a-4527-f2ffd9115242' \
  -d '{
	 "authorization_id": "4f3b8ee1-7a8b-4dc9-bdae-e63e6f0ad9f5",
	 "amount": 1
}'

response 200 OK

{
    "result": "ok",
    "amount": {
        "value": 9,
        "currency": "EUR"
    }
}

Consideration

I assumed the amount in the response of the capture endpoint is the difference from the amount of the transaction and what the client has already captured. I assumed the amount in the response of the refund endpoint is the difference from the amount of the captured and what the client has already refunded.

Points to improve

• more e2e tests
• on the payer layer I would like to handle better the specific edge cases
• when the application authorize the transaction it should crypt the credit card
• client authentication in the header of the request add the client_id and the client_secret to identify the merchant
